The Die Cutting Station includes a Magnetic Cylinder 220T, servo-driven die-cutting cylinder, and automatic pressure system. It supports off-line in-register die-cutting at up to 120 meters per minute. Optional features include a hydraulic pressure readout and semi-rotary die-cutting.

Die Cutting Station Specifications:

  • Magnetic Cylinder 220T:
    • Maximum working width
    • Included magnetic cylinder
    • Servo-driven die-cutting cylinder
    • Automatic die-cut pressure system
    • Optional hydraulic pressure readout with two clocks
    • Control system for off-line in-register die-cutting
    • Maximum machine speed during in-register die-cutting: 120m/min for stable materials
    • Optional semi-rotary die-cutting process
  • Servo-Driven Nip Roller Unit:
    • Can be used as an embossing unit with a magnetic cylinder for flexible embossing plates
  • Buffer Unit:
    • XL die-cut unit with a maximum magnetic cylinder of 340T
  • Matrix Servo-Driven Pneumatic Nip Roller Unit
  • Matrix Rewinder:
    • Servo-driven pneumatic rewind spindle
    • Rewind spindle diameter: 76mm
    • Maximum rewind diameter: 500mm
    • Pneumatic matrix nip roller
  • Stacker XL:
    • Servo-driven vacuum infeed table
    • Three antistatic bars
    • Maximum stack height: 100mm
    • Length range: 50mm to 1050mm
    • Maximum four streams across
    • Hydraulic stacking table
    • Pneumatic outfeed pusher
    • Counter sensor



Contact For Pricing
