The dPack digital press (250mm, 335mm, 520mm) is ideal for small volume orders, efficiently handling variable data and images. It offers production speeds of 20 to 120 meters per minute and ensures a fast turnaround for printed papers, films, and packaging substrates.
Web Width
- STANDARD PRINT ENGINE: 335mm (D-PACK 330), 520mm (D-PACK 510)
- NEW HIQ PRINT ENGINE: 335mm (D-PACK 330), 520mm (D-PACK 510)
Ink Jet Engine Print Width
- STANDARD PRINT ENGINE:
- D-PACK 330: 210mm-282mm-330mm
- D-PACK 510: 352mm-423mm-495mm
- NEW HIQ PRINT ENGINE:
- D-PACK 330: 223mm-298mm-330mm
- D-PACK 510: 371mm-445mm-510mm
Number of Heads per Colour
- STANDARD PRINT ENGINE:
- D-PACK 330: 3-4-5
- D-PACK 510: 5-6-7
- NEW HIQ PRINT ENGINE:
- D-PACK 330: 3-4-5
- D-PACK 510: 6-7-8
Resolution
- STANDARD PRINT ENGINE:
- KM1024im: 360 x 360 dpi, 360 x 720 dpi
- NEW HIQ PRINT ENGINE:
- KMN1800iSHC: 600 x 600 dpi, 600 x 1200 dpi
Drop Size
- STANDARD PRINT ENGINE: 8 pl
- NEW HIQ PRINT ENGINE: 3.5 pl
Print Speeds (CMYK)
- STANDARD PRINT ENGINE: 40 Mts/min, 60 Mts/min
- NEW HIQ PRINT ENGINE: 55 Mts/min, 80 Mts/min
Print Speeds (Mono)
- STANDARD PRINT ENGINE: 80 Mts/min
- NEW HIQ PRINT ENGINE: 100 Mts/min
Drying Systems
- Both engines use LED UV & Mercury UV.
Graphics Software and Converting/Finishing Options
- Both engines include PC, front-end software + RIP, and options for roll-to-roll, corona treatment, web cleaners, anti-static systems, and video inspection.
- Optional software includes Colourgate (automated color management) and Hybrid Software.
File Formats
- Both engines support BMP, JPG, TIFF, PDF, and CSV.
