Cater S
The CATER-S is a versatile semi-automatic core cutter designed for cutting cardboard cores into various lengths. Here are some key technical details:
- Max. parent core length: 2000mm (options for 2500mm and 3000mm)
- Core inside diameter: 38mm-152mm (option for 250mm or 1″)
- Max. wall thickness: Up to 15mm, depending on core ID
- Minimum cut length: Depends on wall thickness
- Max. cut length: 1000mm
- Electric supply: 400 VAC x 3 ph. motor
- Air pressure: 6 bar
- Dimensions for 2000mm: L: 2290mm x W: 640mm x H: 1470mm
- Weight: 175kg
The machine features a specially designed circular knife for quick and dust-free slitting and is built according to European safety standards (CE labeled). Its success is attributed to its simple operation and high technical parameters, making it popular worldwide.
